intel cpu: Allwinner H313
ROM : with 1GB+2GB DDR3
RAM : EMMC 8GB/16GB
OS : andriod 10.0
Wifi : IEEE 802.11a/b/g/n, 2.4G/BT4.1
Previous: MX10 MINI-H313
| Android OS | Android 10.0 os | |
| CPU | Allwinner H313 Quad Core ARM Cortex A53 | |
| GPU | G31 OPenGL ES3.2 | |
| RAM | 2GB DDR3(optional 1GB) | |
| Memory size | 16GB EMMC (optional 8G/32G/64GB) | |
| Language | Chinese,English...Multi-Language support | |
| Storage Extension | Support MicroSD(TF) ，Up to 128GB | |
| WIFI | IEEE 802.11a/b/g/n, 2.4G/BT4.0 | |
| Bluetooth | BT4.0 | |
| Ethernet | Standard 10/100M RJ-45 | |
| Media format: | ||
| Video | Supports video decoding up to 4K60fps | |
| Supports multi-formats:- H.265 Main10L5.1 up to 4K60fps - VP9 Profile 2 up to 4K30fps - AVS2 JiZhun 10bit Profile up to 4K30fps - H.264 BP/MP/HPL4.2 up to 4K30fps - H.263 BP up to 1080p60fps - MPEG-4 SP/ASPL5 up to 1080p60fps - MPEG-2 MP/HL up to 1080p60fps - MPEG-1 MP/HL up to 1080p60fps - Xvid up to 1080p60fps - Sorenson Spark up to 1080p60fps - VP8 up to 1080p60fps - AVS/AVS+ JiZhun Profile up to 1080p60fps - WMV9/VC1 SP/MP/AP up to 1080p60fps - JPEG HFIF file format up to 45MPPS H.264 BP/MP/HP • H.264 supports I/P frame, and only supports single reference frame • MJPEG/JPEG baseline • Maximum 16-megapixel(4096 x 4096) resolution for H.264 encoding • H.264 encoding capability: 1080p60fps • JPEG snapshot performance of 1080p60fps independently • Supports the constant bit rate(CBR)ariable bit rate(VBR) bit rate control mode, ranging from 256kbit/s to 100Mbit/s • Encoding of eight regions of interest(ROIs) | ||
| Audio | Supports MP3, AAC, WMA, RM, FLAC, Ogg | |
| Built-in serial digital audio SPDIF/IEC958 input/output and PCM input/output • Two DAC channels • Supports 1 audio output interface (differential LINEOUTP/N or single-end LINEOUTL/LINEOUTR) • One Audio HUB, supporting internal mixing function • Embedded 3 I2S/PCM (I2S0 for extended audio codec, I2S2 for BT, I2S3 for digital power amplifier) • Supports Left-justified, Right-justified, Standard I2S mode, PCM mode, and TDM mode • I2S mode supports 8 channels, and 32-bit/192kbit sample rate • I2S and TDM modes support maximum 16 channels, and 32-bit/96kbit sample rate • One OWA OUT interface, supporting 16-/20-/24-bit inputs and outputs • Integrated digital microphone(DMIC), supporting maximum 8 digital PDM microphones | ||
| Image | HD JPEG、BMP、GIF、PNG、TIF | |
| Interface: | ||
| 1*HD 2.0 | HD 2.0 up to 6K Output with HDR, CEC and HDCP 2,2, 6K30fps max resolution output | |
| 1*Mirco SD Card (TF) | TF cards (up to 128GB) | |
| 2*USB HOST | 2*USB 2.0,support USB DISK and USB HDD | |
| 1*SPDIF/IEC958 | Support Coaxial | |
| 1*RJ45 | Ethernet:10/100M, standard RJ-45 | |
| 1*Power input | 5V/2A | |
| Accessories: | ||
| power charger | 1 | |
| Remote Control | 1 | |
| giftbox | 1 | |
| User Manual | 1 | |
| HD cable | 1 | |
| Air mouse | optional | |
| wireless mouse | optional | |
| Packing: | ||
| Product size | 115*115*20MM | |
| Net weight | ||
| Gift Box Size | 186*110*53mm | |
| Carton Box Size | ||
| Packing quantity | 40PCS/CTN | |
